Style A square connector

Rectifier

CA - CA11 16H00

CA - CA11 16H00

Heeft u nog vragen over dit product?

Contacteer onze connector specialist

Vraag een offerte aan

Download product sheet

Meer info over dit merk:

Housing Material

PUR
TPR

Article Number	CA14 16H00 501 3000 0
Protection Degree	IP65*
Upper Temperature	+70 °C
Lower Temperature	-40 °C
Contact Type	Fork
Circuits	Rectifier
Housing Oil Resistance	Very good
Housing Hardness	90 shore A
Other Characteristics	M3 central screw material: zinc plated iron
Voltage Vac	1 to 250
Max. Currrent	1,4 A @40°C
Clamping Voltage	320..640 V
Housing Colour	Black
Remark	The IP65 protection degree is valid only if the connector is mounted with the cable exit not upward

Article Number	CA11 16H00 501 3000 0
Protection Degree	IP65*
Upper Temperature	+70 °C
Lower Temperature	-40 °C
Contact Type	Fork
Circuits	Rectifier
Housing Oil Resistance	Occasional contact
Housing Hardness	73 shore A
Other Characteristics	M3 central screw material: zinc plated iron
Voltage Vac	1 to 250
Max. Currrent	1,4 A @40°C
Clamping Voltage	320..640 V
Housing Colour	Black
Remark	The IP65 protection degree is valid only if the connector is mounted with the cable exit not upward

Eigenschappen verschillen tussen varianten en subvarianten
