Techno
Number Of Poles
- 2
- 3
| Article Number | THC.027.A2A |
| Number Of Contacts | 2 |
| Protection Degree | IP00 |
| Upper Temperature | +125 °C |
| Lower Temperature | -40 °C |
| Rated Voltage | 450 |
| Rated Current | 41 A |
| Terminals | Screw |
| Cable Section | max 6,0 mm² |
| T Marking | T125 °C |
| Protection Degree Details | can install inside TEEBOX |
| Tracking Index | PTI 175 |
| Terminal Block Housing | PA66 GF UL94 V0 GWT 960°C brown |
| Contact Screw Terminals | Brass nickel plated |
| Standard / Piercing Screws | M3,5 x 7,5 steel zinc plated |
| Standards | EN60998-1:2004 EN60998-2-1:2004 |
Eigenschappen verschillen tussen varianten en subvarianten
